Dropside Hinge Set
Complete hinge set for dropside vehicles.
- Comprises of
- 1 x gudgeon pin
- 1 x hinge house assembly
- Comes with all relevant fixings including nuts, bolts & washers
- The hinge housing is fixed to the underside of the side plank (also available from our shop)
- Gudgeon is bolted directly onto the side rave channel.
We hold in stock all the associated aluminium planks/hollow side sections & fittings all available from our shop or call for more details.
CODE | A (mm) | B(mm) | C(mm) | D(mm) | E(mm) | F(mm) | G(mm) |
IR209/300 | 99.00 | 76.00 | 30.00 | 12.50 | 49.50 | 20.00 | 12.00 |
